10kW 48V Hybrid All-in-One Parallel Solar Charger Inverter

$1,999.95 $1,699.00 Save 15%
Parallelable
Single Phase / Split Phase / 3-Phase
Buy One Get A Free WIFI Module
 30% Federal Tax Credit

  • Hybrid System: 48V All-In-One Hybrid All-in-One Parallel Solar Charger Inverter
  • Parallelable: Connect up to 6 Units in Parallel (Single Phase / Split Phase / 3-Phase);

  • Rated Power & Peak Power: Output 10kW continuous and 20kW surge power
  • Dual MPPT: Dual MPPT with 99.9% Efficiency
  • Operation Mode: Single Phase(Both 120V&240V model) / Split Phase(Only for 120V model)
  • Output Waveform: Pure Sine Wave
  • UPS: Uninterruptible power supply within 10 milliseconds
  • 4 Charging Modes: Only Solar, Mains Priority, Solar Priority and Mains & Solar hybrid charging
  • LCD Display: Using dynamic flow diagram design, easy to understand the system data and operation status
  • Certifications: CE (IEC62109) / cUL (UL1741 include UL1741-SB) / EMC EN61000 / RoHS Compliant / FCC
  • Communication modules: RS485 / CAN / USB / Dry Contact Port / Wi-Fi (optional) / GPRS (optional)
  • Scheduled Power Control: Features programmable power switching, allowing to set specific time slots for mains charging, battery discharging, and mains bypass power supply mode
  • No Load Power Consumption: <101W (or <78W in low power mode)
  • Compatibility: Compatible with Lead Acid and Lithium Batteries
  • IoT Mobile APP: Real-Time and Remote Smart Controls.
    Style: 120V/240V Parallel
    Shipping & Returns
    • Ship within 2 business days
    • Free Shipping - within 48 contiguous United States
    • Local in stock, available for self-pick-up
    • 30-Day Money Back Guarantee!
    Style: 120V/240V Parallel
    Product information

    Calpha 10kW 48Vdc Hybrid Inverter

    All-in-One Compact Design

    Seamlessly integrating an Inverter, Battery Charger, MPPT Charge Controller, and Grid Charging into a single, streamlined unit, this hybrid inverter offers a comprehensive solution. You can experience the benefits of optimized space utilization, a streamlined setup process, and versatile, efficient power management—all within the convenience of an all-in-one compact design.

    10kW Pure Sine Wave Single Phase / Split Phase / 3-Phase Inverter

    Calpha advanced 10kw 120V inverter features a 110V/240 Split Phase, offering four precise voltage levels per phase: 100Vac, 105Vac, 110Vac, and 120Vac. This feature allows you to precisely tailor the output voltage to match specific needs, optimizing compatibility with various devices and applications. It provides flexibility in addressing voltage variations and ensures efficient power delivery across diverse scenarios, enhancing the overall performance and functionality of the inverter in a wide range of settings.

    Dual 200Amp MPPT Solar Charge Controllers for Higher Power

    Enhance solar power efficiency with our inverter's dual 200Amp MPPT solar charge controllers, each boasting 99.9% efficiency and a 22A current (Max. PV Input) in a single circuit. With the capability to support 2 solar inputs and simultaneous tracking of 2 solar maximum power charging/carrying capacities, it delivers superior performance to maximize your solar energy utilization.

    Peak Demand Management & Off-Peak Load Optimization

    This inverter charger, with its definable time slots, intelligently stores excess solar energy generated during the day in the battery. This stored energy is then readily available for powering home appliances during the evening peak of electricity consumption, ensuring reliable usage and substantial reductions in energy expenses. Additionally, the Non-Dischargeable Battery State feature transforms the inverter into an uninterruptible power supply (UPS).

    Dual Activation Function

    The Calpha hybrid inverter offers dual activation, allowing either mains or photovoltaic power supply access to trigger the activation of the Li-ion battery. Once activated, it promptly delivers reliable backup power, seamlessly integrating into diverse systems and empowering you to choose the preferred power source and harness the benefits of both technologies.

    Monitor & Manage with Ease

    Unlock the full potential of the solar inverters for homes with the Calpha IoT mobile app. With the IoT mobile app, you can enjoy the benefits of real-time monitoring, remote control, energy insights, and seamless integration of your inverters and batteries' operating status.

    Flexible Charging & Output Modes

    Versatile solar inverter that comes equipped with four charging modes (Solar Only, Mains Priority, Solar Priority, Hybrid Charging) and 2 output modes(Utility Bypass and Inverter Output). This versatility allows tailored energy management, ensuring optimal efficiency and adaptability to various power scenarios, ultimately maximizing your control and convenience.

    All-round protection

    The Calpha solar inverter is equipped with over 10 comprehensive protection functions, ensuring the safety and longevity of both the inverter and the connected solar power system. These protection mechanisms include complete short circuit protection, overvoltage and undervoltage protection, overload protection, backfilling protection, and so on. With these advanced protection features, you can have peace of mind knowing that the solar power system is safeguarded against various potential risks and faults.

    Unleashing the Power of Advanced Features

    With a lightning-fast response time of less than 0.01 seconds, Calpha hybrid solar pure sine inverter charger ensures an immediate reaction to power outages, ensuring uninterrupted operations for your critical devices and appliances.

    Calpha’s solar inverter is equipped with dual automatic cooling fans. These intelligent fans constantly monitor system temperature, adjusting their speed to maintain optimal operating conditions, enhancing efficiency, reliability, and significantly extend the lifespan of your solar power system.

    Stay informed and in control with the Calpha smart solar inverter charger's LCD display, providing real-time charging and loading information at your fingertips. With its clear and intuitive interface, you can easily monitor the performance of your solar energy system and stay updated on its status.

    Effortlessly integrate your hybrid power system with a range of energy storage options, offering compatibility with both Lead Acid and Lithium batteries for versatile energy solutions. Experience streamlined control and monitoring through a user-friendly interface that includes RS485, CAN, USB, Dry Contact Port, and optional Wi-Fi/GPRS communication modules, providing you with convenient and adaptable management of your entire power system.

    AC Split Phase (120V model)
    Output Phase: L1/L2/N/PE(L1/L2 split) Output Rated Phase Power: 5000W/5000W
    Output Rated Phase Voltage: 120VAC/120VAC Output Rated Phase Current: 41.7A/41.7A
    Output Frequency: 50Hz or 60Hz Input Phase: L1/L2/N/PE(L1/L2 split)
    Input Rated Phase Power: 5000W/5000W Input Rated Phase Voltage: 120VAC/120VAC
    Input Max Phase Current: 63A/63A Input Frequency: 50Hz or 60Hz
    Input Phase Voltage Range: 90-140VAC/90-140VAC Input Charge to Battery: 120A

    AC Single Phase(120V/230V model)
    Output Phase: L/N/PE Output Rated Power: 10000W
    Output Rated Voltage: 120VAC/230VAC Output Rated Current: 83.3A/43.5A
    Output Frequency: 50Hz or 60Hz Input Phase: L/N/PE
    Input Rated Power: 10000W Input Rated Voltage: 120VAC/230VAC
    Input Voltage Range: (90-140VAC)/(90-280Vac/170-280Vac) Input Max Current: 126A
    Input Frequency: 50Hz or 60Hz Charge to Battery Current: 120A


    PV Input
    Num. of MPP Trackers: 2 Max.PV Input Power: 5500W+5500W
    Max. Input Current: 22A+22A Max. Voltage of Open Circuit: 500VDC
    MPPT Voltage Range: 125-425VDC

    Battery Compatibility
    Battery Type: Compatible with Lead Acid and Lithium Batteries Rated Battery Voltage: 48VDC
    Battery Voltage Range: 40-60VDC Max. MPPT Charging Current(Battery): 200A
    Max.Mains/Generator Charging Current: 120A Max. Hybrid Charging Current: 200A

    Mains/Generator Input
    Input Voltage Range: (90-140VAC)/(90-280Vac/170-280Vac) Frequency Range: 50/60Hz
    Bypass Overload Current: 63A

    General
    MPPT Tracking Efficiency: 99.9% Max. Battery Inverter Efficiency: 92%
    Dimension: 620*445*130mm (2*1.5*0.4ft) Weight: 27kg(59lb)
    Waterproof Rating: IP20 Operating Temperature Range: -10~55℃,>45℃ derated(14~131℉,>113℉ derated)
    Noise: <60dB Communication: RS485/CAN/USB/Dry contact/Wi-Fi(Optional)/GPRS(Optional)
    Safety: IEC62109-1,IEC62109-2,UL1741,EMC,RoHS
